INSTALLING THE GEAR UNIT
Dana Incorporated IMM-0017EN - Installation and Maintenance Manual
Standard type brakes basic wiring diagram
DANGER
The electric connection must be done by experienced electric technician.
The gearbox and the motor must be grounded to prevent potential differences of earth and gearbox/motor.
Delayed Running Brake ( 220 V) Sudden Brake (220 V)
Delayed Running Brake ( 24 V) Sudden Brake (24 V)
M
3
RST
A
A
M
3
R
S T N
A
M
3
SR NT
A
N
M
3
RST
