MECHANICAL INSTALLATION
Dana Incorporated IMM-0017EN - Installation and Maintenance Manual
8.1 INSTALLING CUSTOMER SHAFT WITH SHOULDER
Use anti-seize assembling paste available on your market. Use a brush to apply the paste.
Fasten the bold as shown below.
1 - Retaining Bolt
2 - Lock Washer
3 - Washer
4 - Circlips
5 - Hollow Shaft
6 - Customer Shaft
