Brigade Electronics BE-870EM - Specifications

13
SPECIFICATIONS
LCD panel specifications
Size/Type 7" (Diagonal) TFT LCD
Brightness 400 cd/m
2
(min)
450 cd/m
2
(typ)
Contrast ratio 250 (min)
300 (typ)
View angles
(@ CR
≥ 10)
Top (12
o'clock)
30° (min)
Bottom (6
o’clock)
50° (min)
Horizontal ±50° (min)
Response time Rise: 15ms (typ) ; 30ms (max)
Fall: 20ms (typ) ; 40ms (max)
Backlight type LED
Backlight life 20,000 hrs (min)
• Operation temperature range: -20°C ~ +65°C
• Storage temperature range: -30°C ~ +85°C
• Operation voltage range: DC 10.5V ~ 32V
• Current draw (typical): Max 15W
• Signal system: NTSC or PAL (Auto switching)
• Video Aspect ratio: 16:9
Input level: 1Vp-p 75Ω
• Audio Input level: Max 0.5W
• Vibration: 15G
• Dimensions: 197(w) x 138(h) x 32.2(d)mm
7.75(w) x 5.43(h) x 1.3(d) inch
• Weight: Approx. 650g
• Supplied accessories: Mounting bracket (1)
Screw kits (1)
Power cord (1)
Instruction manual (1)
Remote contol (1)
Sun visor (1)
