5.3.5 BS-9000 Sensor CAN ID (Connected Sensors)
The CAN ID of each connected BS-9000 radar sensor dictates the on-screen location of
the coloured indicator related to that sensor.
The image below illustrates the range of available on-screen indicator locations vs the BS-
9000 radar sensor CAN ID required for each one.
The Connected Sensors area of the Main Control Window enables the user to view and
reconfigure the CAN ID values of up to 2 connected BS-9000 sensors. Pressing the Refresh
button will show the CAN ID’s in the Registration field
As default, BS-9000 sensors are manufactured and shipped with a reserved CAN ID of 0x390,
(see BS-9000 Installation and Operating Guide for further details).
System installers must re-configure the CAN ID of each sensor from 0x390 to one of the
available ID values in the range 0x310 to 0x380. Sensors must be re-configured one at a
time so that 2 sensors with the same CAN ID are never connected to the system at the
same time.
