Specifications
Built-in Camera 112° Viewing Angle
Max Recording Resolution Built-in camera: 1280x720: Auxiliary camera 640x480
Recording Frame 1CH : 30fps, 2CH : 17fps / 13fps
Video Compression H. 264 MPEG4
Recording Modes INFINITE / EVENT / PARKING / EMERGENCY
Operating Voltage 12V-24Vdc
Operating Temperature -10°C ~ 60°C
Storage Temperature -20°C ~ 70°C
Dimension 85(W)mm X 50(H)mm X 24(D)mm (Body only)
Weight 60g (Recorder only)
Current Consumption Max 260mA@12V (Without auxiliary camera)
Operating voltage 12-24Vdc
Video output 1VP-P 75Ω NTSC
SD Card Micro SD Class 6 - Max size 32Gb
1. G-Sensor Value to operate Event mode (Values in G)
Level 9 Level 8 Level 7 Level 6 Level 5 Level 4 Level 3 Level 2 Level 1 Level 0 AXIS
Front/Back 1.31 1.25 1.18 1.12 1.06 1.0 0.93 0.87 0.81 0.75 x
Left/Right 1.37 1.31 1.25 1.18 1.12 1.06 1.0 0.93 0.87 0.81 y
Up/Down 1.40 1.34 1.28 1.21 1.15 1.12 1.06 1.0 0.93 0.84 z
2. G-Sensor value for enabling Parking Mode.
When the G-Sensor value stays under 0.08G for 10 minutes, Parking Mode
will be enabled.
3. G-Sensor value for disabling Parking Mode.
When the G-Sensor value stays above 0.08G for more than 4 seconds,
Parking Mode will be disabled.
4. G-Sensor value for starting Parking Mode recordings.
When the G-Sensor value exceeds 0.08G.
