50 BRIGGSandSTRATTON.COM
Engine Specifications - Model 200000 Horizontal Series
ENGINE SPECIFICATIONS
Armature Air Gap 0.010 - 0.014 in. (0.25 - 0.36 mm)
Crankshaft End Play 0.002 - 0.028 in. (0.05 - 0.71 mm)
Spark Plug Gap 0.030 in. (0.76 mm)
Valve Clearance - Intake 0.004 - 0.006 in. (0.10 - 0.15 mm)
Valve Clearance - Exhaust 0.004 - 0.006 in. (0.10 - 0.15 mm)
FASTENER TORQUE SPECIFICATIONS TORQUE
Air Cleaner Base / Backplate 90 lb-in. (10 Nm)
Armature 30 lb-in. (3 Nm)
Blower Housing 90 lb-in. (10 Nm)
Carburetor Bowl Screw / Solenoid 90 lb-in. (10 Nm)
Carburetor to Cylinder Head 85 lb-in. (10 Nm)
Connecting Rod 100 lb-in. (11 Nm)
Control Bracket 100 lb-in. (11 Nm)
Control Panel Trim 40 lb-in. (5 Nm)
Crankcase Cover 100 lb-in. (11 Nm)
Cylinder Head 220 lb-in. (25 Nm)
Cylinder Shield 30 lb-in. (3 Nm)
Exhaust Manifold / Adapter 180 lb-in. (20 Nm)
Flywheel Nut 120 lb-ft. (160 Nm)
Flywheel Fan 140 lb-in. (16 Nm)
Flywheel Guard 30 lb-in. (3 Nm)
Fuel Tank 90 lb-in. (10 Nm)
Governor Lever Nut 40 lb-in. (5 Nm)
Muffl er 180 lb-in. (20 Nm)
Muffl er Support Bracket 125 lb-in. (14 Nm)
Oil Drain Plug 100 lb-in. (11 Nm)
Oil Fill Tube 30 lb-in. (3 Nm)
Rewind Starter 30 lb-in. (3 Nm)
Rocker Arm Stud 100 lb-in. (11 Nm)
Rocker Ball Set Screw or Nut 45 lb-in. (5 Nm)
Spark Plug 180 lb-in. (20 Nm)
Starter Cover 20 lb-in. (2 Nm)
Starter Motor 140 lb-in. (16 Nm)
Rocker Cover 75 lb-in. (8 Nm)
