Briggs & Stratton E Series - ENGINE DIMENSIONS

Page 2 of 12
ENGINE DIMENSIONS
Dimensions are shown in inches (millimeters).
4.746
(120.54)
7.442
(189.04)
6.21
(157.7)
7.41
(188.3)
13.62
(345.96)
7.442
(189.04)
2.41
(61.15)
1.56
(39.7)
3.68
(93.54)
3.19
(81.15)
3.02
(76.68)
9.13
(231.98)
Figure 2
