Level 0 Level 1 (On screen) Level 2 (On screen) Parameters (On screen)
Display
(DISPLAY)
Contrast
(CONTRAST)
0 – 100 %
Power Save Mode
(POWER SAVE MODE)
Disable/Enable
Communication
(COMMUNICATION)
Communication Mode
(COMM MODE)
None/MODBUS
* Slave ID
(MODBUS SLAVE ID)
1 – 247
* Baudrate
(MODBUS BAUDRATE)
1200/2400/4800/9600/19200/
38400/57600/115200 bps
* Parity Bit
(PARITY BIT)
None/Even/Odd
Auto Exercise
(AUTO EXERCISE)
Exercise Option
(EXER OPTN)
No Exercise/Standard
Exercise
Cycle
(EXER CYCLR)
No run/0.1/5/10/15/20 min run
Event Occurence
(EXER EVENT OCCR)
Weekly/Monthly
Event Day
(EXER EVENT DAY)
Weekdays/1 – 28 days
Start Time
(EXER START TIME)
00:00 – 23:59 hour
Exercise Skip Enable
(EXER SKIP ENABLE)
Yes/No
45 min Burn Off
(45 MIN BURN OFF)
45 min Burn Off
(45 MIN BURN OFF)
Disable/Enable
Event Month
(EVENT MONTH 1)
March/April/May/None
Event Day
(EVENT DAY 1)
1 - 28
Start Time
(EVENT START TIME 1)
00:00 – 23:59 hour
Event Month
(EVENT MONTH 2)
August/September/
October/None
Event Day
(EVENT DAY 2)
1 - 28
Start Time
(EVENT START TIME 2)
00:00 – 23:59 hour
Digital Inputs
(INPUTS)
Digital Input X
(DIG IN X)
X= A/B/C/D/E
* Source
(SOURCE)
* Polarity
(POLARITY)
Close to Activate/Open to
Activate
* Action
(ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Activation
(ACTIVATION)
Never/From Engine Start/
From Monitoring On/Always
* Activation Delay
* (ACTIVATION DELAY)
1 – 60 sec
Analog Inputs
Analog Input 1
* Use Input As
Not used/Digital Input G/Anlg
