Briggs & Stratton GC1031 - Page 13

Not for
Reproduction
Page | 7
Level 0 Level 1 (On screen) Level 2 (On screen) Parameters (On screen)
(AMB TEMP/DIG G) (USE INPUT AS) In Amb Temp
* Circuit Fault Action
(CKT FAULT ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Ambient Temperature Sensor
Calibration Table
Analog Input 2
(FUEL LVL/DIG H)
* Use Input As
(USE INPUT AS)
Not used/Digital Input H/Anlg
In Fuel LVL
* (Digital) Source
((DIG) SOURCE)
* (Digital) Polarity
((DIG) POLARITY)
Close to Activate/Open to
Activate
* (Digital) Action
((DIG) ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* (Digital) Activation
((DIG) ACTIVATION)
Never/From Engine Start/
From Monitoring On/Always
* (Digital) Activation Delay
((DIG) ACTIVATION DELAY)
1 – 60 sec
* Low Fuel Level Shutdown
(SHUTDOWN)
Disable/Enable
* Low Fuel Level Shutdown
Threshold
(SHUTDOWN THRESHOLD)
0 – 78 %
* Low Fuel Level Notification
(NOTIFICATION)
Disable/Enable
* Low Fuel Level Notification
Threshold
(NOTIFICATION THRESH)
2 – 80 %
* Fuel Tank Capacity
(FUEL TANK CAPACITY)
2 – 1000 litre
* Fuel Theft Warning
(FUEL THEFT ALARM)
Disable/Enable
* Fuel Theft Alarm Threshold
(FUEL THEFT THRESHOLD)
1 – 100 % per hour
* Circuit Fault Action
(CKT FAULT ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Fuel Sensor Reference
(FUEL SENSOR REFERENCE)
Engine Body/Battery Negative
* Fuel Level Sensor Calibration
Table
Analog Input 3
(LOP RES/ DIG F)
* Use Input As
(SENSOR SELECTION)
Not used/Digital Input F/Anlg
In LOP
* (Digital) Source
((DIG) SOURCE)
* (Digital) Polarity
((DIG) POLARITY)
Close to Activate/Open to
Activate
* (Digital) Action
((DIG) ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* (Digital) Activation
((DIG) ACTIVATION)
Never/From Engine Start/
From Monitoring On/ Always
* (Digital) Activation Delay
1 – 60 sec
