Briggs & Stratton GC1031 User Manual

Not for
Reproduction
Page | 8
Level 0 Level 1 (On screen) Level 2 (On screen) Parameters (On screen)
((DIG) ACTIVATION DELAY)
* Low Level Shutdown
(SHUTDOWN)
Disable/Enable
* Low Level Shutdown Threshold
(SHUTDOWN THRESHOLD)
0.0 – 9.8 bar
* Low Level Warning
(WARNING)
Disable/Enable
* Low Level Warning Threshold
(WARNING THRESHOLD)
0.2 – 10.0 bar
* Circuit Fault Action
(CKT FAULT ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Lube Oil Pressure Sensor
Calibration Table
Analog Input 4
(LOP CURR/ DIG I)
* Use Input As
(SENSOR SELECTION)
Not used/Digital Input I/Anlg
In LOP(4 – 20mA)
* (Digital) Source
((DIG) SOURCE)
* (Digital) Polarity
((DIG) POLARITY)
Close to Activate/Open to
Activate
* (Digital) Action
((DIG) ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* (Digital) Activation
((DIG) ACTIVATION)
Never/From Engine Start/
From Monitoring On/ Always
* (Digital) Activation Delay
((DIG) ACTIVATION DELAY)
1 – 60 sec
* Shutdown
(SHUTDOWN)
Disable/Enable
* Shutdown Threshold
(SHUTDOWN THRESHOLD)
0.0 – 9.8 (0.0 – 9.8 Bar)
* Warning
(WARNING)
Disable/Enable
* Warning Threshold
(WARNING THRESHOLD)
0.2 – 10.0 (0.2 – 10.0 Bar)
* Circuit Fault Action
(CKT FAULT ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Lube Oil Pressure Sensor
Calibration Table
Outputs
(OUTPUTS)
Output X
(OUT X)
X= A/B/C/D/E/F
* Source
(SOURCE)
* On Activation
(ON ACTIVATION)
Energize/De-energize
Timers
(TIMERS)
Cranking
(CRANKING
TIMER)
* Crank Hold Time
(CRANK HOLD TIME)
3 – 15 sec
* Crank Rest Time
(CRANK REST TIME)
2 – 60 sec
* Manual Start Delay
(MANUAL START DELAY)
0 – 30 sec
* Auto Start Delay
(AUTO START DELAY)
0 – 43200 sec
General Timer
* Safety Monitoring Delay
10 – 60 sec

Briggs & Stratton GC1031 Specifications

General

Brand	Briggs & Stratton
Model	GC1031
Category	Controller
Language	English
