Page | 9
Level 0 Level 1 (On screen) Level 2 (On screen) Parameters (On screen)
(GENERAL TIMER) (SAFETY MONITOR DELAY)
Mains Detect Delay
(MAINS DETECT DELAY)
1 – 300 sec
* Alternator Detect Delay
(ALT DETECT DELAY)
1 – 60 sec
Warm-Up Delay
(WARM UP DELAY)
0 – 60 sec
Return To Mains Delay
(RETN-TO-MAINS DELAY)
0 – 600 sec
* Engine Cooling Time
(ENG COOL TIME)
0 – 300 sec
* Stop Action Time
(STOP ACTION TIME)
10 – 120 sec
* Additional Stopping Time
(ADDN STOPPING TIME)
0 – 120 sec
Load Transfer Delay
(LOAD TRANSFER DELAY)
0 – 60 sec
Power Save Mode Delay
(PWR SAVE MODE DELAY)
5 – 1800 sec
Sounder Alarm Time
(SOUNDER ALARM TIMER)
1 – 300 sec
Auto Exit Config Mode
(AUTO EXIT CNFG TMR)
10 – 1800 sec
Generator
(GENERATOR)
Alternator
Configuration
(ALT CONFIG)
* Alternator Present
(ALT PRESENT)
No/Yes
* Number Of Poles
(NUMBER OF POLES)
2/4/6/8
* AC system
(ALT AC SYSTEM)
Single Phase 2 Wire/ Single
Phase 3 Wire/ Three Phase 4
Wire (1Ph 2 wire/1Ph 3
wire/3Ph 4 wire)
* Min Healthy Voltage
(MIN HEALTHY VOLT)
50 – 350 Volt Ph-N
* Min Healthy Frequency
(MIN HEALTHY FREQ)
10 – 75 Hz
* Phase Reversal Detection
(PHASE REVERSE DETECT)
Disable/Enable
* Phase Reversal Action
(PHASE REVERSE ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Auto Load Transfer
(AUTO LOAD TRANSFER)
Disable/Enable
* Genset Nominal Voltage
(NOMINAL VOLTAGE (L-L))
100 – 650 Volt L-L
* Genset Nominal Frequency
(NOMINAL FREQUENCY)
10.0 – 75.0 Hz
Voltage Monitoring
(VOLT MONITOR)
* Under-voltage Shutdown
(UNDER VOLT SHUTDOWN)
Disable/Enable
* Under-voltage Shutdown
Threshold
(UV SHUTDWN THRESHLD)
50 – 295 Volt Ph-N
