Page | 10
Level 0 Level 1 (On screen) Level 2 (On screen) Parameters (On screen)
* Under-voltage Warning
(UNDER VOLT WARNING)
Disable/Enable
* Under-voltage Warning
Threshold
(UV WARNING THRESHOLD)
55 – 300 Volt Ph-N
* Over-voltage Shutdown
(OVER VOLT SHUTDOWN)
Disable/Enable
* Over-voltage Shutdown
Threshold
(OV SHUTDWN THRESHLD)
105 – 350 Volt Ph-N
* Over-voltage Warning
(OVER VOLT WARNING)
Disable/Enable
* Over-voltage Warning
Threshold
(OV WARNING THERSHOLD)
100 – 345 Volt Ph-N
Frequency
Monitoring
(FREQ MONITOR)
* Under-frequency Shutdown
(UNDER FREQ SHUTDOWN)
Disable/Enable
* Under-frequency Shutdown
Threshold
(UF SHUTDWN THRESHLD)
10.0 – 59.0 Hz
* Under-frequency Warning
(UNDER FREQ WARNING)
Disable/Enable
* Under-frequency Warning
Threshold
(UF WARNING THRESHOLD)
11.0 – 60.0 Hz
* Over-frequency Shutdown
(OVER FREQ SHUTDOWN)
Disable/Enable
* Over-frequency Shutdown
Threshold
(OF SHUTDWN THRESHLD)
26.0 – 75.0 Hz
* Over-frequency Warning
(OVER FREQ WARNING)
Disable/Enable
* Over-frequency Warning
Threshold
(OF WARNING THRESHOLD)
25.0 – 74.0 Hz
Current Monitoring
(CURRENT
MONITOR)
* CT Ratio
(CT RATIO)
0 – 8000 / 5
* Over-current Action
(OVER CURR ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Over-current Threshold
(OVER CURR THRESHOLD)
5 – 10000 Amp
* Over-current Delay
(OVER CURR DELAY)
1 – 600 sec
* CT Location
(CT LOCATION)
On Load Cable/On Alt Output
Cable
Load Monitoring
(LOAD MONITOR)
* Generator Rating
(GEN RATING)
0 – 8000 kW
* Over-load Action
(OVERLOAD ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Over-load Threshold
(OVERLOAD THRESHOLD)
50 – 150 %
