Level 0 Level 1 (On screen) Level 2 (On screen) Parameters (On screen)
* Over-load Monitoring Delay
(OVERLOAD MON DELAY)
1 – 600 sec
* Unbalanced Load Action
(UNBAL LOAD ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
* Unbalanced Load Threshold
(UNBAL LOAD THRESHOLD)
5 – 200 %
* Unbalanced Load Delay
(UNBAL LOAD DELAY)
1 – 600 sec
* Extended Over-load Trip
(EXT OL TRIP)
Disable/Enable
* Extended Over-load Trip
Threshold
(EXT OL THRESHOLD)
50 – 150 %
Mains
(MAINS)
Configuration
(MAINS CONFIG)
Mains Monitoring
(MAINS MONITORING)
Disable/Enable
* Mains AC system
(MAINS AC SYSTEM)
Single Phase 2 Wire/Single
Phase 3 Wire/Three Phase 4
Wire (1Ph 2 wire/1Ph 3 wire
/3Ph 4 wire)
* Phase Reversal Detection
(PHASE REVERSE DETECT)
Disable/Enable
* Phase Reversal Action
(PHASE REVERSE ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
Under-voltage
Monitoring
(UNDER VOLT
MON)
* Under-voltage
(ENABLE)
Disable/Enable
* Trip
(TRIP)
50 – 298 Volt Ph-N
* Return
(RETURN)
52 – 300 Volt Ph-N
Over-voltage
Monitoring
(OVER VOLT MON)
* Over-voltage
(ENABLE)
Disable/Enable
* Trip
(TRIP)
102 – 350 Volt Ph-N
* Return
(RETURN)
100 – 348 Volt Ph-N
Under-frequency
Monitoring
(UNDER FREQ
MON)
* Under-frequency
(ENABLE)
Disable/Enable
* Trip
(TRIP)
10.0 – 59.0 Hz
* Return
(RETURN)
11.0 – 60.0 Hz
Over-frequency
Monitoring
(OVER FREQ MON)
* Over-frequency
(ENABLE)
Disable/Enable
* Trip
(TRIP)
26.0 – 75.0 Hz
* Return
(RETURN)
25.0 – 74.0 Hz
Engine
(ENGINE)
Crank Disconnect
(CRANK DISCON)
* Start Attempts
(START ATTEMPTS)
1 – 9
* Disconnect On Oil Pressure
Disable/Enable
