31
•
•
•
•
•
•
FLIPELO (HD810, HD1010, and HD2000 only)
Reverses the coordinates of the touch screen. This keyword isn’t used in the example above, and
it should be used only if the touch screen coordinates appear to be reversed.
GPIOEnableInput <GPIO number> (HD410, HD810, and HD1010 only)
Sets the specified GPIO port as an input port.
GPIOEnableOutput <GPIO number> (HD410, HD810, and HD1010 only)
Sets the specified GPIO port as an output port.
SerialPortSpeed <port speed> (HD410, HD810, HD1010, and HD2000 only)
Sets the baud rate for the serial line. Supported baud rates are: 1800, 2000, 2400, 3600, 4800,
7200, 9600, 12800, 14400, 19200, 23040, 28800, 38400, 57600, 115200.
SerialPortMode <port mode> (HD410, HD810, HD1010, and HD2000 only)
Sets the serial mode. The format is:
SerialPortMode:8N1
• The first character is the number of data bits. You can enter 5, 6, 7 or 8.
• The second character is the parity. N = none, O = odd, and E = even.
• The third character is the number of stop bits. You can enter 1 or 2.
UDPDestinationAddress <address> (HD1010 and HD2000 only)
Specifies the destination IP address in dotted quad form.
UDPDestinationPort <port number> (HD1010 and HD2000 only)
Specifies the destination port for UDP packets.
FLIPELO
IMAGEMODE 2
EVENTS elo:110:180:355:210
