NOTE: With the help of a friend,
turn the cart over. Try to
minimize the stress to the
side panels.
Step 3
Attach locking casters to the bottom
of the cart. Tighten caster bolts
securely using hex nut wrench
provided in parts pack.
NOTE: With the help of a friend,
turn the cart to its upright
position.
Step 4
Attach back cart panel by using six
M6 X 60mm bolts.
NOTE: Leave bolts hand tight until
Step 9.
24
Locking Caster
Hex Nut Wrench
