WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN AS SEM BLING THIS UNIT.
The following tool is required to assemble this Brinkmann 5 Burner Gas Grill:
• Phillips Head Screwdriver
PARTS LIST:
1 Grill Body Assembly
1 Left Side Table
1 Sear Burner Assembly
1 Sear Burner Grate
1 Left Side Table Front Panel
1 Right Side Table Front Panel
1 Sear Burner Control Knob
1 Sear Burner Bezel
1 Warming Rack
3 Cooking Grills
5 Heat Distribution Plates
1 Left Side Cart Panel
1 Right Side Cart Panel
1 Upper Cart Brace
1 Upper Door Brace
1 Cart Base
1 Left Side Door
1 Right Side Door
1 Grease Tray
1 Tank Heat Shield
2 Cart Corner Brackets
1 Smoke Box
1 Smoke Box Bracket
1 Sear Burner Grease Tray
1 Grease Cup
2 Locking Swivel Casters
2 Swivel Casters
19
11
12
13
14
15
16
10
1
2
3
5
6
7
8
9
4
To see troubleshooting or assembly videos, visit us at
26
27
17
18
19
21
22
23
24
25
20
