Step 5
To attach the upper door brace,
insert the pre-attached bolts on the
upper door brace through the key
holes on the right and left side cart
panels.
Step 6
Attach left side door by inserting the
bottom door pins into the cart base.
Align the hole at the top of the door
with the hole in the upper cart brace
and inert one door hinge pin through
both holes. Repeat for other door.
23
Upper Door
Brace
Door Hinge Pin
Right Side Door
Left Side Door
To Next Page
