29
Step 17
Attach the tank heat shield under
the grease tray using two
M4 x 10 mm bolts (black).
Step 18
Slide the grease tray onto the tracks
located behind and underneath the
grill body assembly.
Step 19
Hang grease cup from the grease
tray. Make sure to slide up onto
tracks as illustrated.
Grease Tray
Tank Heat
Shield
Grease Cup
To Next Page
