Step 22
Place two D batteries into the light
battery compartment and slide
compartment into the sleeve under
the left side table front.
Step 23
Attach light wire with light switch.
Step 24
Remove igniter cap and insert one
AA battery with positive end of the
battery toward igniter cap. Replace
igniter cap and make sure the
igniter is working properly.
Main Control
Panel
(Front)
igniter Cap
To Next Page
