17
Lap-Shoulder Belt Installation • Press the base firmly into the
vehicle seat while removing all
slack from first the lap portion
and then the shoulder portion
of the vehicle seat belt.
• Hold the vehicle belt tight and
close the upper portion of the
lock-off.
• Press firmly on the upper
portion of the lock-off and
close the lower portion to
secure.
• Verify that the vehicle belt is tight and that the base is secure.
The base is secure when it moves less than 2.5 cm (1 in.) front-
to-back or side-to-side at the vehicle belt path.
• Correct recline angle is achieved when the green markers on
the recline angle indicators are visible between the two lines.
Installing with Base
