STROLLER ASSEMBLY
ATTACHING THE STORAGE BASKET
17
1
2
ATTACHING THE STORAGE BASKET
A Position the storage basket into the area under the seat. Slide the hook tabs at
the front of the basket (No. 1) behind the metal bar and attach to the loop tabs
on the basket to secure. Slide the hook tabs on the side of the basket (No’s. 2
& 3) behind the metal bar and attach to the loop tabs on the basket to secure.
Slide the hook tab (No. 4) through the brackets on the inside of the frame and
attach to the loop tabs on the basket to secure.
B Wrap the hook tabs on the rear of the storage basket around the axle and
attach to the loop tab to secure.
4
3
2
1
