6
Compatible Vehicle Seat Belts
NOTE: The information in this section only applies to installation
with vehicle seat belts.
Vehicle seats and seat belts differ from vehicle to vehicle. Refer to
your vehicle owner’s manual for specific information about your
vehicle seat belts and their use with child seats.
Lap-Shoulder (3-Point) Belt
1. ALR (Automatic Locking Retractor) with Sliding Latch Plate
a Has a latch plate that freely
slides along the vehicle seat
belt webbing.
b Has a retractor that stops the
belt from being pulled out
again once the belt webbing
has been pulled out at least
61 cm (24 in.).
c Tightens by feeding the
belt webbing back into the
retractor.
2. ELR (Emergency Locking Retractor) with Locking Latch Plate
a Has a latch plate that locks
the vehicle belt.
* This type of latch plate locks
the vehicle belt when the
vehicle belt and latch plate lie
flat. When using this type of
vehicle belt with a child seat,
ensure the latch plate and
vehicle belt lie flat against the
child seat or the vehicle belt
may remain unlocked.
b
Has a retractor that locks
only in an emergency
situation such as sudden
stop or crash.
3. Switchable Retractor in ALR Mode with Sliding Latch Plate
a Has a latch plate that freely
slides along the vehicle
seat belt webbing.
Vehicle Compatibility
Latch
plate
Latch
plate
Latch
plate
To Next Page
