Removing the Cover
WARNING! Never remove the buckle tongues from the
harness. They cannot be reattached after removal. If reassembled
incorrectly, the child seat may not perform as intended.
1 Loosen the harness.
a Lift release lever
b Pull both harness straps forward
6 Unhook both harness straps
from the yoke.
2 Open the chest clip.
a Press tabs
b Pull apart
3 Unbuckle the harness.
4 Remove the infant body pillow
if necessary.
5 Remove the belly pad from the
harness buckle.
a Pull the buckle through the belly
pad
b Remove the elastic strap from
around the buckle
8
Detach the plastic hooks from
the bottom edge of the child
seat.
7 Pull the harness straps
through the shell and cover to
the front of the child seat.
