Service Manual 32 – Contour 3 Series, Profiler & Advance – Approved Issue 5 Printed 2/13/2014 11:50:17 AM
16
Brivis Technical Data
Type: Technical Data Base Date Updated: 15/01/2004
Category: Specification Sheet - Cooler
Subject: Profiler P 23
Sizing Guide Reference Figure 1250 - 1800
Cabinet detail
Width 1100 mm
Height front 720 mm
Height back 400 mm
Length 1100 mm
Dry Weight 47.0 kg
Wet Weight 64.8 kg
Filter Pad Details
Quantity 4
Thickness 75 mm
Type CELDEK 5090
Duct Outlet Size
Width 550 mm
Length 550 mm
Pump / Water Distribution
Motor Pump Type ASKOLL M115
Type 240 V - 1 ph Pump Rating 240 V / 0.2 Amps
Model FASCO Pump Capacity 20 L/minute
855BNVA-A12 Winding Resistance 206 Ohm (+/- 8% @ 20
o
C)
Watts 315 Overflow size 40 mm
Amps 2.4 Waste Outlet Size 40 mm
R.P.M. 1400 Tank Capacity 12 Litres
Capacitor Size 8 uF Distribution Hose Size 20 mm CLEAR HOSE
R.P.M Min Setting 500 Inlet Valve Type ELBI E.V Type 329
R.P.M Max Setting 1350 Inlet Valve Rating 240 V - 0.03 Amps
N-E5 Model Selection Model 1 Inlet Valve Capacity 4 L or 5.5L/minute
Coil Resistance 4.1 kOhm approx. @ 20
o
C
Inlet Valve Size 3/4" BSP (Male) Thread
Fan Impellor Auto Refresh Tube
Size 538 mm Dia.. Type S.A.I.A
Type BRIVIS 538-6-23 Rating 240 V 50 Hz 0.23 Watt
Blades 6 RPM 500
Blade Angle 23 deg TIP Resistor 470 Ohm
Collet BRIVIS Capacitor 100 nF
Cooler Control Module Wall Controller
N-E5 BWC-1 (Electronic)
BWC-2 (Manual)
Networker N-C3
Water Connection
Flexible Hose Connection with 1/2" BSP (Male) Thread
Drain Connection
40 mm PVC
