Service Manual 32 – Contour 3 Series, Profiler & Advance – Approved Issue 5 Printed 2/13/2014 11:50:17 AM
23
Brivis Technical Data
Type: Technical Data Base Date Updated: 06/06/2005
Category: Specification Sheet - Cooler
Subject: Brivis Advance F 33
Sizing Guide Reference Figure 1500 - 2250
Cabinet detail
Width 1100 mm
Height front 590 mm
Height back 590mm
Length 1100 mm
Dry Weight 49 kg
Wet Weight 67 kg
Filter Pad Details
Quantity 4
Thickness 75 mm
Type CELDEK 5090
Duct Outlet Size
Width 550 mm
Length 550 mm
Pump / Water Distribution
Motor Pump Type ASKOLL M115
Type 240 V - 1 ph Pump Rating 240 V / 0.2 Amps
Model FASCO Pump Capacity 20 L/minute
80855BQVA-A22V Winding Resistance 206 Ohm (+/- 8% @ 20
o
C)
Watts 750 Overflow size 40 mm
Amps 4.9 Waste Outlet Size 40 mm
R.P.M. 1350 Tank Capacity 15 Litres
Capacitor Size 25 uF Distribution Hose Size 20 mm CLEAR HOSE
R.P.M Min Setting 500 Inlet Valve Type ELBI E.V Type 329
R.P.M Max Setting 1150 Inlet Valve Rating 240 V - 0.03 Amps
N-E5 Model Selection Model 3 Inlet Valve Capacity 4 L/minute
Coil Resistance 4.1 kOhm approx. @ 20
o
C
Inlet Valve Size 3/4" BSP (Male) Thread
Fan Impellor Auto Refresh Tube
Size 538 mm Dia. Type S.A.I.A
Type BRIVIS 538-11-30 Rating 240 V 50 Hz 0.23 Watt
Blades 11 RPM 500
Blade Angle 30 deg TIP Resistor 470 Ohm
Collet BRIVIS Capacitor 100 nF
Cooler Control Module Wall Controller
N-E5 BWC-1 (Electronic)
BWC-2 (Manual)
Networker N-C3
Water Connection
Flexible Hose Connection with 1/2" BSP (Male) Thread
Drain Connection
40 mm PVC
