Brivis SP623EN User Manual

Outlet Register Chart
Table 3.
System
Model
Airow
Rate
(L/s)
A
Maximum
Ceiling
B
Typical
Floor
C
Minimum
Floor/Ceiling
D
Minimum
Floor/Ceiling
(Adaptive ZoningOnly)
SP5 & SP6 Heaters
External
SP630EN 850 15 23 7 3
SP630EN-XA 985 17 23 7 3
SP530EN 960 16 23 7 2
SP530EN-XA 965 17 23 7 2
SP623EN 715 12 12 5 2
SP623EN-XA 755 13 12 5 2
SP521EN 700 12 12 5 1.5
SP521EN-XA 740 13 12 5 1.5
SP5 & SP6 Heaters
Internal
SP635IN 1130 17 24 7 2.5
SP535IN 1160 17 24 7 2.5
SP630IN 1065 16 22 7 3
SP630IN-XA 1095 17 22 7 3
SP530IN
1080 17 24 7 2
SP530IN-XA
1140 17 24 7 2
SP623IN
765 12 13 5 2
SP623IN-XA
795 14 13 5 2
SP521IN
785 12 13 5 1.5
SP521IN-XA
830 14 13 5 1.5
SP615IN
695 12 13 5 2
SP4 Heaters
Universal
SP415UN 620 10 12 6 2
SP421UN 621 10 12 6 2
SP430UN 918 16 23 7 2
SP435UN 1004 17 23 7 3
Buffalo BX5
External
BX520EN (300mm)** 605 10 12 5 2
BX520EN (350mm)** 667 12 13 6 2
BX526EN (350mm)** 944 16 23 7 2
BX526EN (400mm)** 1011 17 23 7 3
** Model and basebox duct size
Note: Airflow figures are based on a total static pressure of 125 Pa for 30 & 35 models and 50 Pa for other models.
Note: Brivis Network 516 modules can only be used on heaters manufactured after 1 Mar 2010.
11. Thermostat Installation
All Brivis heating systems can be controlled by various Brivis Thermostats, each explained in detail below. A
Thermostat inside the house is wired to the control module in the heater. The Thermostat monitors the temperature
in the house, and switches the system ON and OFF in order to maintain a set temperature. So it must be
positioned correctly.
• Install in the living area: It is important that the Thermostat is placed in a position that will provide the most
accurate reading of the temperature, i.e. in the area most often used for family living.
• Attach on an internal wall: The temperature difference on an external wall can also affect it, so always
mount it on an internal wall. Keep the hole in the wall for the wiring as small as possible to prevent draught
from within the wall cavity affecting the temperature setting.
• Get the height right: The Thermostat should be approximately 1500mm above the floor level.
20
324702 CAAB024953 StarPro Installers Heat issue D.indd 23 17/05/16 8:41 AM
