MODELS B3030SS • B3036SS
Page 2
SOFFIT
24" - 30" ABOVE
COOKING SURFACE
CABINET
3¼" X 10" DUCT
(For horizontal discharge)
WALL CAP
ROOF CAP
3¼" X 10" or 7" ROUND DUCT
(For vertical discharge)
HOUSE WIRING
(Top or Back of hood)
HOODHOOD
CLEANING & MAINTENANCE
Forperformance,appearance,andhealthreasons,cleanlter,
fanandgrease-ladensurfaces.Useonlyacleanclothandmild
detergentsolutiononstainlessandpaintedsurfaces.
Cleanall-metalltersinthedishwasherusinganon-phosphate
detergent.Discolorationoftheltermayoccurifusingphosphate
detergents,orasaresultoflocalwaterconditions-butthiswill
notaffectlterperformance.Thisdiscolorationisnotcovered
bythewarranty.
Cleanthenon-ductrecirculatingltersurfacesfrequentlywith
adampclothandamilddetergent.DONOTimmerseltersin
waterorputindishwasher.Thespecial“CleanSense”feature
indicateswhenthelteristobereplaced.Theblueandyellow
stripswillblendtogreenwhenitistimetochangethelter.The
“CleanSense”featureworksbestwhenfacingtowardthecook-
ingsurface.Changethenon-ductrecirculatingltersevery6
months.Forreplacementnon-ductrecirculatinglters-purchase
S97018088orModelFILTER30.
Themotorispermanentlylubricatedandneverneedsoiling.If
themotorbearingsmakeexcessiveorunusualnoise,replace
themotorwiththeexactservicemotor.Theimpellershouldalso
bereplaced.
PREPARE HOOD LOCATION
1 Determinewhetherhoodwilldischargevertically(3¼”
x10”or7”Round),orhorizontally(3¼”x10”only).For
verticalorhorizontaldischarge,runductworkbetween
thehoodlocationandaroofcaporwallcap.Forbest
results,useaminimumnumberoftransitonsandelbows.
2 Usetheproperdiagrambelow,forplacementofductwork
andelectricalcutoutincabinetorwall.Foranon-ducted
installation,DONOTcutaductaccesshole.
3¼” X 10”
VERTICAL DUCTING
OPERATION
AlwaysturnthehoodONbeforecookinginordertoestablishan
airowinthekitchen.Afterturningofftherange,letthehoodrun
forafewminutestocleartheair.
Operatethehoodasfollows:
BLOWER SWITCH
This3-positionrockerswitchturnsblowerONandOFFand
controlsblowerspeed.
FrontrockerpositionturnsblowerONtohighspeed.
CenterrockerpositionturnsblowerOFF.
BackrockerpositionturnsblowerONtolowspeed.
LIGHT SWITCH
This3-positionrockerswitchturnslightsONandOFFand
controlstheirintensity.
FrontrockerpositionturnslightsONtohighintensity.
CenterrockerpositionturnslightsOFF.
BackrockerpositionturnslightsONtolowintensity.
ON (high)
OFF
ON (low)
BLOWER
ON (high)
OFF
ON (low)
LIGHTS
VERTICAL DUCT
ACCESS HOLE
¾"
10
5
/
8
"
5¼"
5¼"
CENTER
LINE
HOOD MOUNTING SCREWS (4)
ELECTRICAL
ACCESS HOLE
(in cabinet bottom)
WOOD SHIMS
(recessed-bottom
cabinets only)
CABINET FRONT
CABINET
BOTTOM
15
5
/
8
" (36" hood)
4½"
2"
15
5
/
8
" (36" hood)
12
5
/
8
" (30" hood)
12
5
/
8
" (30" hood)
2
5
/
8
"
8
5
/
8
"
NOTE
This hood utilizes an offset blower design to achieve greater
performanceandlowersoundlevels.Asaresult,you maynotice
thatcookingimpuritiesaremoreattractedtoonesideorappear
tobepulled-infasterthantheyappearontheoppositeside.This
iscompletelynormal.Thehoodhasbeendesignedandtested
toprovidegoodcaptureofcookingimpuritiesandodorsunder
all normalcookingconditionsregardlessofthecookinglocation
onthecooktop.Pleasenotethatcookingontherearburnerswill
alwaysresultinthebestcaptureofcookingimpurities,regardless
ofthehooddesign.
