Broan B3030SS - Prepare the Hood

MODELS B3030SS • B3036SS
Page 3
ELECTRICAL
ACCESS HOLE
(in cabinet bottom)
15
5
/8" (36" hood)
2"
15
5
/8" (36" hood)
12
5
/8" (30" hood)
12
5
/8" (30" hood)
8
5
/8"
10
5
/8"
2
5
/8"
HOOD MOUNTING SCREWS (4)
4
5
/8"
7-IN. ROUND
DUCT
ACCESS
HOLE
7-IN. ROUND
DUCT
ACCESS
HOLE
8" DIA.
HOLE
CABINET
BOTTOM
CABINET FRONT
HORIZONTAL DUCT
ACCESS HOLE
5¼"
5¼"
HOOD
MOUNTING
SCREWS (4)
ELECTRICAL
ACCESS HOLE
(in wall)
4"
CENTER
LINE
WOOD SHIMS
(recessed-bottom
cabinets only)
15
5
/8" (36" hood)
12
5
/8" (30" hood)
15
5
/8" (36" hood)
12
5
/8" (30" hood)
8
5
/8"
1
3
/16"
3
/8"
3¼” X 10”
HORIZONTAL DUCTING
7-IN. ROUND
DUCTING
PREPARE THE HOOD
6 Removedamper/ductconnectorandpartsbagfrom
insidethehoodpackage.
FOR DUCTED INSTALLATIONS - Skip to Step 9.
ALUMINUM
FILTERS
4 RemovetheAluminum Filtersfromthehood.
(2)
LIFT
OUT
(1)
PULL
DOWN
↑
↑
3 Removeallprotectivepolyfilmfromthehood.
5 Removethelightpanelsfromthehood.Depressthe
springtabonthebacksideofeachpanelandrotate
outward.Disconnectelectricalconnectors.
