INSTALL LIGHT BULBS
19 Thisrangehoodrequires(2)Halogen Bulbs(120V,50
W,shieldedhalogenbulbs-typeMR16withGU10base-
included).
 NOTE:Suction Cup Toolcanbeusedtoinstalland
removelightbulbs.Donotdiscard-saveforfutureuse.
 Alignpinsonbulbwithlargediameteropeningonsocket,
thenpushbulbintowardshoodandrotateclockwiseuntil
firmlyseated.
 Thepositionofthebulbsocket(depth)isadjustableand
maybenecessarywhen:
 a)certainbrandsofbulbsaredifficulttoinstall.
 b)thebulbprotrudestoofarbelowthelightpanel.
(1)
PUSHIN
CAUTION: Bulbs may be hot. Refer to bulb
packaging for further information.
(2)
ROTATECLOCKWISE
SUCTION
CUPTOOL
HALOGEN
BULB
21 DUCTED INSTALLATION ONLY:
Re-installaluminumfiltersremovedinStep4.
NON-DUCTED INSTALLATION ONLY:
Installaluminumfiltersandnon-ductedfilters-purchased
andassembledinStep10.
CONNECT THE WIRING
18 ConnectHouse Power Cabletorangehoodwiring-
BLACKtoBLACK,WHITEtoWHITE,andGREENor
BAREWIREtoGround Screw.Replaceelectricalwiring
boxcover.
HOUSE
POWER
CABLE
GROUND
SCREW
20 Re-installlightpanelsremovedinStep5.
 Tochangethedepthofbulbsockets:
-Removelightpanels(SeeStep5).
-Loosen2ScrewsholdingLamp Socket Bracketto
 Light Panel.
-Adjustsocket/brackettodesireddepth.
-Re-tightenscrewssecurely.
-Re-attachlightpanels.
LAMPSOCKET
BRACKET
SCREWS
LIGHT
PANEL
