11 DUCTED INSTALLATION ONLY:
Remove3¼”x10vertical,3¼”x10”horizontal,or7-inch
roundknockout plate(s)asappropriateforyourducting
method.
 NOTE:Theknockoutforhorizontalductingisslightly
smallerthanthewidthofthe3¼”x10”ductconnector.
Aligntheductconnectorwiththehoodcenterline(±½”),
NOTcenteredonthehorizontalknockoutopening.
3¼”X10”
HORIZONTAL
KNOCKOUT
PLATE
3¼”X10”
VERTICAL
KNOCKOUT
PLATE
7”ROUND
KNOCKOUT
PLATE(also
remove3¼”x10”
verticalplate)
8 NON-DUCTED INSTALLATION ONLY:
RemoveMetal DiverterfromFront Slotandplaceinto
Rear Slot.
METAL
DIVERTER
FRONT
SLOT
REAR
SLOT
REAR
SLOT
9 NON-DUCTED INSTALLATION ONLY:
ReplaceNon Duct Diverter Covers.
7 NON-DUCTED INSTALLATION ONLY:
RemoveNon Duct Diverter Coversheldinplacewith
(4)Screws.
NONDUCT
DIVERTER
COVERS
SCREWS
10 NON-DUCTED INSTALLATION ONLY:
Purchaseasetof(2)non-ductedfilters(ModelFILTER30)
fromyourlocaldistributororretailer.Attachthenon-
ductedfilterstothealuminummeshfiltersfollowing
instructionspackedwiththenon-ductedfilters.
FOR NON-DUCTED INSTALLATIONS - Skip to “INSTALL
THE HOOD”.
