Broilermaster H3X-2 - H3 X Series Parts List

B102163-0-1113 Page 11
H3X SERIES PARTS LIST
Index No. Part Description
Part Number
H3X H3XN
1 Grill Body Top (with heat indicator, hinge, B102042 B102042
1 Grill Body Top (casting only) B100456 B100456
2 Heat Indicator (stainless) DPP119 DPP119
3 Lid Handle (stainless) B070486 B070486
4 Foam Grip B073097 B073097
5 Warming Rack (Chrome) B100594 B100594
6 Cooking Grid (two piece Stainless Steel) B101397 B101397
7 Briquette Bag B058122 B058122
8 Briquette Rack B101061 B101061
9 Burner Assembly DPP109 DPP109
10 Wind Deector B063065 B063065
11 Bridge Pin B057805 B057805
12 Hinge Pin B057804 B057804
13** Lid Stop Kit DPA106 DPA106
14 Orice - LPG (#55 drill) P182 P182
15 Orice - NAT (#49 drill) P265 P265
16 Electric Ignitor B072218 B072218
17* Valve - LPG (without orices) B101420 B101420
18* Valve - NAT (without orices) B101421 B101421
19 Shelf Pin B073963 B073963
20 Control Panel Assembly (with label) B101563 B101563
20 Control Panel Label (not shown) B101517 B101517
21 Valve Knob - Black B070084 B070084
22 Grill Body Bottom (casting only) B101879 B101879
23 Control Panel Shield B101622 B101622
24 Electrode Bracket B101834 B101834
25 Electrode B101666 B101666
26 Protective Sleeve B102041 B102041
27 Burner Bracket DPP118 DPP118
28 Hose & LPS Regulator B069756 N/A
29 Push Nut B101665 B101665
30 Mounting Plate Assembly B101997 B101997
31 Collector Box Assembly DPP116 DPP116
NS Hardware Package B101971 B101971
NS Ignitor Ground Wire B072684 B072684
NS - Not Shown
*Valves are not convertible. To convert the unit to a different gas type, a new valve must be purchased.
**Note: H3 Series grills do not come with a Lid Stop Kit. The Lid Stop Kit must be purchased separately.
