B102163-0-1113Page 34
HARDWARE PACK
DESCRIPTION PART NUMBER QUANTITY SUPPLIED
Screw 1/4-20 x 3/4 PH Truss Head SS B063096 6
Spacer, Ignitor (R3B Only) B101082 1
Screw #10-24 x 1 Phillips Truss Stainless B073978 2
Knob R3918 2
Battery, AA N/A 1
Foam Grip B073097 1
Ground Wire (R3 Only) B072684 1
Collector Box Assembly (R3B Only) B101212 1
SPACER, IGNITOR
FOAM GRIP
BATTERY, AA
KNOB
COLLECTOR BOX ASSEMBLY
SCREW 1/4-20 X 3/4 PH TRUSS HEAD SS
SCREW #10-24 X 1 PHILLIPS TRUSS STAINLESS
GROUND WIRE
R3 ONLY
R3B ONLY
R3B ONLY
