Broilermaster H3X-2 - H4 X Series Parts List

B102163-0-1113 Page 13
H4X SERIES PARTS LIST
Index No. Description
Part Number
H4X H4XN
1 Grill Body Top (with heat indicator, hinge) B102043 B102043
1 Grill Body Top (casting only) B076621 B076621
2 Heat Indicator (stainless) DPP119 DPP119
3 Lid Handle (stainless) B070486 B070486
4 Foam Grip B073097 B073097
5 Warming Rack (stainless) B072696 B072696
6 Cooking Grid DPA114 DPA114
7 Briquette Bag DPA34 DPA34
8 Briquette Rack B067449 B067449
9 Burner Assembly DPP115 DPP115
10 Wind Deector B101742 B101742
11 Bridge Pin B057805 B057805
12 Hinge Pin B057804 B057804
13** Lid Stop Kit DPA106 DPA106
14 Orice - LPG (#122 mm) P312 P312
15 Orice - NAT (#50 drill) P245 P245
16 Electric Ignitor B072218 B072218
17* Valve - LPG (without orices) B101420 B101420
18* Valve - NAT (without orices) B101421 B101421
19 Shelf Pin B073963 B073963
20 Control Panel Assembly (w/label and shield) B102168 B102168
20 Control Panel Label B101518 B101518
21 Valve Knob - Black B070084 B070084
22 Grill Body Bottom (casting only) B101443 B101443
23 Control Panel Shield B101621 B101621
24 Collector Box Assembly DPP116 DPP116
25 Electrode Bracket B101834 B101834
26 Electrode B101666 B101666
27 Protective Sleeve B102041 B102041
28 Burner Bracket DPP118 DPP118
29 Push Nut B101665 B101665
30 Mounting Plate Assembly B101997 B101997
31 Hose & LPS Regulator B069756 N/A
NS Hardware Package - LPG & NAT DPP116 DPP116
NS Ignitor Ground Wire B072684 B072684
NS - Not Shown
*Valves are not convertible. To convert the unit to a different gas type, a new valve must be purchased.
**Note: H4 Series grills do not come with a Lid Stop Kit. The Lid Stop Kit must be purchased separately.
