Broilermaster H3X-2 - P3 X Series Parts List

B102163-0-1113 Page 7
P3X SERIES PARTS LIST
Index
No.
Description Part Number
P3SX P3SXN P3X P3XN P3XF P3XFN
1 Grill Body Top (with heat indicator, hinge) B102042 B102042 B102042 B102042 B102042 B102042
1 Grill Body Top (casting only) B101883 B101883 B101883 B101883 B101883 B101883
2 Heat Indicator (stainless) with push nut DPP119 DPP119 DPP119 DPP119 DPP119 DPP119
3 Lid Handle (stainless) B070486 B070486 B070486 B070486 B070486 B070486
4 Foam Grip B073097 B073097 B073097 B073097 B073097 B073097
5 Retract-A-Rack (stainless) B072695 B072695 B072695 B072695 B072695 B072695
6 Cooking Grid (two piece Stainless Steel DPA111 DPA111 DPA111 DPA111 DPA111 DPA111
7 Briquette Bag N/A N/A DPA34 DPA34 N/A N/A
8 Briquette Rack B101061 B101061 B101061 B101061 B101061 B101061
9 Burner Assembly DPP111 DPP111 DPP111 DPP111 DPP111 DPP111
10 Wind Deector B101742 B101742 B101742 B101742 B101742 B101742
11 Bridge Pin B057805 B057805 B057805 B057805 B057805 B057805
12 Hinge Pin B057804 B057804 B057804 B057804 B057804 B057804
13 Lid Stop Kit DPA106 DPA106 DPA106 DPA106 DPA106 DPA106
14 Orice - LPG (#54 drill) P204 P204 P204 P204 P204 P204
15 Orice - NAT (#48 drill) P300 P300 P300 P300 P300 P300
16 Electric Ignitor B072218 B072218 B072218 B072218 B072218 B072218
17* Valve - LPG (without orices) B101420 B101420 B101420 B101420 B101420 B101420
18* Valve - NAT (without orices) B101421 B101421 B101421 B101421 B101421 B101421
19 Shelf Pin B073963 B073963 B073963 B073963 B073963 B073963
20 Control Panel Assembly (with label and shield) B102167 B102167 B102167 B102167 B102167 B102167
20 Control Panel Label (not shown) B101517 B101517 B101517 B101517 B101517 B101517
21 Valve Knob - Black B070084 B070084 B070084 B070084 B070084 B070084
22 Grill Body Bottom (casting only) B101879 B101879 B101879 B101879 B101879 B101879
23 Control Panel Shield B101622 B101622 B101622 B101622 B101622 B101622
24 Electrode Bracket B101834 B101834 B101834 B101834 B101834 B101834
25 Electrode B101666 B101666 B101666 B101666 B101666 B101666
26 Protective Sleeve B102041 B102041 B102041 B102041 B102041 B102041
27 Flare Busters Kit DPA116 DPA116 N/A N/A DPA116 DPA116
28 Burner Bracket DPP118 DPP118 DPP118 DPP118 DPP118 DPP118
29 Push Nut B101665 B101665 B101665 B101665 B101665 B101665
30 Hose & LPS Regulator B069756 N/A B069756 N/A B069756 N/A
31 Griddle, Stainless Steel B101400 B101400 N/A N/A N/A N/A
32 Smoker/Shutter (includes Actuator Arm & Knob DPA100 DPA100 N/A N/A N/A N/A
33 Collector Box Assembly DPP116 DPP116 DPP116 DPP116 DPP116 DPP116
NS Ignitor Ground Wire B072684 B072684 B072684 B072684 B072684 B072684
NS Hardware Package B101973 B101973 B101973 B101973 B101973 B101973
NS Actuator Arm - Smoker/Shutter B100408 B100408 N/A N/A N/A N/A
NS Knob - Smoker/Shutter Knob B100098 B100098 N/A N/A N/A N/A
NS - Not Shown
*Valves are not convertible. To convert the unit to a different gas type, a new valve must be purchased.
