Bromic Heating TUNGSTEN 300 - Fenwal Control, White Rodgers Gas Valve

N
L
E
White
Black - 110 V
Blue
Green
Black HT Cable
Blue
Ignition + ionisation
FENWAL
24 V
SEE INSTRUCTION MANUAL FOR DETAILS ON HOW
TO CONNECT THE ELECTRICAL COMPONENTS.
GND.
V 2
White
S 1.
T H
V 1
Red
Orange
Yellow/Green
TRANSFORMER
WHITE
RODGERS
Note:
If any of the original wire as supplied with the heater must be replaced, it must be replaced with 18AWG, 90ºC type UL
approved wire or its equivalent. If Transformer must be replaced, a UL approved model of similar type must be used.
ionisation
WIRING DIAGRAM - FENWAL CONTROL, WHITE RODGERS GAS VALVE
