Bromic Heating TUNGSTEN 300 - Wiring Diagrams; Honeywell Control, Honeywell Gas Valve

WIRING DIAGRAM - HONEYWELL CONTROL, HONEYWELL GAS VALVE
12
11
10
9
8
7
6
5
4
3
2
1
N
L
E
White
Black 110 V
N/A
Yellow/Green
Yellow/Green
Yellow/Green
Green
White
Black
Ignition +
Ionisation
HONEYWELL
Red 230 V
Blue
Purple
Purple
Note:
If any of the original wire as supplied with the heater must be replaced, it must be replaced with 18AWG, 90ºC type UL
approved wire or its equivalent. If Transformer must be replaced, a UL approved model of similar type must be used.
SEE INSTRUCTION MANUAL FOR DETAILS ON HOW
TO CONNECT THE ELECTRICAL COMPONENTS.
TRANSFORMER
