2. Installation
Installation Requirements User Manual
2. Installation
Installation Requirements
The following information contains information you need for installation of the P-102.
Power Specifications
The following table includes electrical specification for the P-102.
Electrical Properties Specifications
Voltage/Frequency/Phase
(±10%)
200 VAC @ 50 Hz - Single Phase
208-230 VAC @60 Hz - Single Phase
Inrush Current 41 Amps (locked rotor amps)
Maximum Continuous
Current
11.5 Amps Maximum
Rated Load Amps 7.5 Amps
Overvoltage Category Category II
Disconnect Device
The disconnect device is customer supplied. It should be rated for minimum 10
KAIC. The P-102 is not provided with a circuit breaker or a disconnect device.
Table 2-1: Electrical Specifications
Site Requirements
The following table lists Site Specifications.
2-15 Brooks Automation
