2. Installation
User Manual Installation Requirements
Environmental Factors Specifications
Temperature:
Ambient Air During Operation
Shipping
Storage
50Hz Operation
15 – 30° C (59 – 86° F)
-20 – +49° (-4 – +120° F)
A room temperature of 4 – 49° C (40 – 120° F), non condensing
Temperature will be approximately 5°C Warmer.
Relative Humidity 20 – 80%, non-condensing relative humidity
Lighting
Standard lighting is sufficient for proper operation. Maintenance may require
a service lamp or flashlight.
Transport The P-102 must remain in a vertical position.
Install Location
Be sure to allow 18 inches in front of and to the rear of the P-102.
Well ventilated area greater than 2200 ft
3
Above ground
Service Access
The P-102 requires adequate space for service access and for proper
ventilation. Typical service space required is shown in Figure 2-1 .
Allow 36 inches to the left and right sides of the P-102 for service areas.
Ground Clearance 1 7/8 inches
Rolling Provision Four casters
Lifting Provision Use a fork lift
Hold-Down Provision
None. Determine if the P-102 is being used in an earthquake prone area. If
so, the customer needs to provide tie-downs to prevent the P-102 from
moving during an earthquake.
Table 2-2: Environmental Specifications
NOTE: The facility is responsible ensuring the Cryocooler P-102 installation complies with the local
electric codes.
Service and Exclusion Zones
Place the P-102 so that the area indicated in Figure 2-1 is available for service and ventilation.
Accelerating Innovation 2-16
