Brother 882-W33 User Manual

SPECIFICATIONS
194
*1
The wireless network connection complies with IEEE 802.11b/g/n standards and uses the 2.4 GHz frequency.
A wireless network cannot be set up with WPA/WPA2 Enterprise.
Use Design Database Transfer or PE-DESIGN version 11 or later to transfer data from your computer to the machine. For the operating
systems compatible with the software, visit our website “ https://s.brother/cndka/
”.
*2
“.pmv”, “.pmu” or “.pmx” stitch data files can be retrieved; however, when the machine is used to save the file, it is saved as a “.pmp”
stitch data file. Using data other than what was created using this machine or the machine which create “.pmp”, “.pmv”, “.pmx” or “.pmu”
data file, may cause the machine to malfunction.
*3
Using data other than that saved using our data design systems or this machine may cause this machine to malfunction. When the
machine is used to save a file with any extension, it is saved as a .phx data file.
Since Tajima (.dst) data does not contain specific thread color information, it is displayed with our default thread color sequence. Check
the preview and change the thread colors as desired.
*4
Some USB media may not be usable with this machine. Please visit our website “ https://s.brother/cpdab/ ” for more details.
* Please be aware that some specifications may change without notice.
SPECIFICATIONS
Item Specification
Dimensions of machine Approx. 690 mm (W) × 322 mm (D) × 349 mm (H)
(approx. 27-11/64 inches (W) × 12-43/64 inches (D) × 13-47/64 inches (H))
Weight of machine Approx. 19.6 kg (approx. 43.2 lb)
Dimensions of machine with
embroidery unit attached
Approx. 973 mm (W) × 576 mm (D) × 349 mm (H)
(approx. 38-5/16 inches (W) × 22-43/64 inches (D) × 13-47/64 inches (H))
Weight of machine with embroidery
unit attached
Approx. 24.4 kg (approx. 53.7 lb)
Sewing speed 70 to 1050 stitches per minute
Maximum embroidery speed 1050 stitches per minute
Compatible interface
Wireless LAN
*1
Memory Stitch patterns 1 MB
Embroidery patterns 10 MB
My Design Center 100 MB
Data types
Stitch patterns
*2
.pmp, .pmv, .pmx, .pmu
Embroidery patterns
*3
.pes .phc .phx .dst .pen
Data that can be loaded when
using My Design Center
.jpg (up to 4 MB), .png (up to 4 MB), .bmp (up to 8 MB)
Number of decorative stitch pattern
combinations
Up to 70
Embroidery pattern size Maximum of 408 mm (H) × 272 mm (W) (approx.16 inches (H) × 10-5/8 inches (W))
Types of USB Devices/ Media that
can be used
*4
Stitch patterns, Embroidery
patterns
Data can be saved to or recalled from USB media. Use media that
meets the following specifications.
• USB Flash drive (USB Flash memory)
Embroidery data can be recalled only.
• USB external CD/DVD drives
Condition of the [Eco Mode] and
[Shutoff Support Mode]
[Eco Mode] Available time OFF, 10 - 120 (minute)
“Start/Stop” button Green flashing
Suspended function Machine light, Screen display
After recovering The machine starts from the
previous operation.
[Shutoff Support Mode] Available time OFF, 1 - 12 (hour)
“Start/Stop” button Green slow flashing
Suspended function All functions
After recovering An error message appears.
You need to turn off and on the
machine to restart.
Compatible image files of the Screen
Saver Image
Format .jpg
File size Max. 150 KB for each image
File dimension 800 × 800
Number allowed 5 or less
Videos that can be played MP4 file format Video - H.264/MPEG-4 AVC, Audio – AAC
Size 450 (H) × 800 (W)
Maximum file size 1 GB

Brother 882-W33 Specifications

General

Brand	Brother
Model	882-W33
Category	Sewing Machine
Language	English
