Brother AE1700 User Manual

KNOWING YOUR SEWING MACHINE ————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————
—————
9
5
Lower the presser foot lever and fix the
presser foot onto the shank. If the presser
foot is in the correct place, the bar should
snap in.
1 Shank
2 Bar
■ Presser foot installation orientation
CAUTION
THE CONTROLS
Pattern selection dial
CAUTION
To choose a stitch, simply turn the pattern selection dial
in either direction.
1 Pattern selection dial
2 Chosen pattern number
Patterns and stitch names
■ 17 Stitches
1
2
● If the presser foot is not installed with
the correct orientation, the needle may
strike the presser foot, which may bend
or break the needle and cause injury.
● When you use the pattern selection dial
to choose a pattern, raise the needle by
turning the handwheel toward you
(counterclockwise) so that the mark on
the wheel points up. If the needle is in
the down position when you turn the
pattern selection dial, the needle, presser
foot or fabric may be damaged.
2
1
Pattern
Preset Length
(mm (inch))
Reference
Page
Stitch Name
Preset Width
(mm (inch))
0.5 (1/32)
30
4-STEP AUTOMATIC
BUTTONHOLE
5 (3/16)
1.6 (1/16)
26, 34
STRAIGHT STITCH
(Center Needle
Position)
—
1.8 (1/16)
26,34
STRAIGHT STITCH
(Center Needle
Position)
—
1
2
3 4
5
6
7
8
9
10
11
12
13
14 15 16 17
1
2
3

Brother AE1700 Specifications

General

Stitch Number	17
Buttonhole Style	4-step
Sewing Light	Yes
Free Arm	Yes
Bobbin Type	Horizontal
Foot Controller	Yes
Type	Mechanical
Stitch Functions	17
Buttonhole Styles	1
Needle Threader	Yes
Presser Feet	Buttonhole foot, Zipper foot
