Brother BE-0901E-AC-PC

Questions and Answers

T
Tammy LittleAug 18, 2025
What to do if my Brother BE-0901E-AC-PC does not operate even if the power is turned on?
- M
  Mary LeeAug 18, 2025
  If your machine isn't operating even when powered on, first ensure the power cord is properly plugged in. Next, check that the connector in the control box is correctly connected, paying attention to the types and colors of the connectors. Finally, inspect fuse F1 or F5 on the power PCB in the control box; if blown, replace it. If the fuse blows again, there may be a fault requiring a check of the wiring or replacement of the control box.
A
amber17Aug 21, 2025
What to do if my Brother BE-0901E-AC-PC is not embroidered properly?
- B
  browntheresaAug 21, 2025
  If your embroidery isn't coming out properly, check if the material edge is caught in the machine and ensure the embroidery hoop and related parts are operating correctly. Verify that the material is stretched properly and that the thread tension is correct. Also, ensure that the lower thread comes out smoothly.
N
ngreeneAug 25, 2025
What to do if my Brother BE-0901E-AC-PC Sewing Machine displays 'Release stop SW to operate!'?
- R
  rebecca55Aug 25, 2025
  If the message "Release stop SW to operate!" is displayed, it indicates that the stop switch (an optional feature) is turned on. Reset the stop switch to resolve this issue.
C
Catherine RobinsonAug 28, 2025
What causes an overtravel error on my Brother BE-0901E-AC-PC?
- K
  Kevin JonesAug 28, 2025
  An overtravel error can occur if the frame is not within the cap frame area. To resolve this, move the frame within the cap frame area and turn on the power. Also, check if the signal of the X area sensor turns ON and OFF in PORT test mode. If the signal does not change, check the connection from the X cap sensor to the main PCB, referring to the cable connections diagram. If necessary, replace the X cap sensor.
C
Chase FullerSep 3, 2025
Why does the needle stop position error occur on my Brother BE-0901E-AC-PC?
- C
  Christina RichardsSep 3, 2025
  A needle stop position error can occur if the pulley is manually turned and out of the stop angle; turn the pulley to adjust the needle at the stop position and reset the error. Check the signal of the stop position sensor in the encoder test mode. Refer to the adjustment or cable connection block diagram and check the connection from the needle position detention sensor to the main PCB. If necessary, replace the needle position detection sensor. Also, verify if the main shaft brake solenoid is operating, checking the cable connections from the brake solenoid to the power PCB and from connector P27 of the power PCB to connector P1 of the main PCB.
E
emily82Sep 7, 2025
What causes the E-A8 error on my Brother BE-0901E-AC-PC Sewing Machine?
- M
  martinezdeniseSep 7, 2025
  If the E-A8 error occurs frequently, manually turn the main shaft pulley in the encoder signal test mode and check that the stop position signal is correct. If the signal does not change, refer to the cable connection block diagram and check the connection from the stop position sensor to the main PCB.
B
Bryce WhitakerSep 10, 2025
Why don't all the solenoids of the head operate on my Brother Sewing Machine?
- M
  Megan SanchezSep 10, 2025
  If all solenoids of the head do not operate, refer to the block diagram showing cable connections and check fuse F2 on the power supply PCB. If it is blown, replace it. If the fuse is blown immediately after turning on the power even after replacing the fuse, the 60v circuit is faulty.
S
Spencer JacksonNov 13, 2025
Why is my Brother Sewing Machine thread breaking?
- D
  donna82Nov 13, 2025
  Thread breakage can occur due to several reasons. Ensure the machine is properly threaded, the thread tension isn't too high, and the rotary hook assembly isn't clogged. Also, check if there's thread in the bobbin, if the needle is bent, or if there's a rough edge on the needle plate, rotary hook, or bobbin case. Verify the needle is installed correctly, the presser foot is in contact with the material, and the thread thickness and needle size are appropriate. Using a thread with a right-hand twist can also cause breakage; replace it with a left-hand twist thread. Other potential causes include adhesive on the needle, weak material tension, excessive play between the rotary hooks, a non-smooth outer rotary hook, incorrect clearance between the rotary hook stopper and hook, or thread not co...
D
Dr. Rachel Jones MDDec 1, 2025
What causes the main shaft motor lock error on my Brother Sewing Machine?
- K
  kevin03Dec 1, 2025
  If the INDEX motor is not rotating, check the connection from the INDEX motor to the main PCB, referring to the cable connections diagram. Check the resistance values of pins 1 and 2 and pins 3 and 4 at the connector section of the INDEX motor (normal resistance is approximately 10 ohms); if not normal, replace the INDEX motor and the main PCB. If the main shaft motor doesn't rotate at all when the error occurs, check fuses F1 and F5 on the power supply PCB in the control box. Also, check the connection from the main shaft motor to the main PCB, connectors P15 and P16 of the main PCB, connectors P1 and P2 on the power PCB, and connector P14 of the main PCB to the 14v terminal of the power transformer. Manually turn the main shaft pulley in the encoder signal test mode and check to see if t...

Summary

Introduction to Embroidery Machine

Machine Specifications Overview

Details the technical specifications of the embroidery machine, including sewing speed, area, and power.

Software Requirements and Operation Basics

Covers necessary PC systems, software configuration, notes on use, help, and basic software operations.

Preparation of Embroidery Machine

Machine Components Identification

Identifies the main components of the BE-0901E-AC-PC and BE-1201B-AC-PC embroidery machines.

Machine Installation and Setup Procedures

Details the steps for transporting, installing, connecting PC/power, and setting up the embroidery machine software.

Embroidery Preparation Steps

Outlines essential preparation steps before embroidering, including threading, bobbin replacement, and tension adjustment.

Embroidering Procedures

Operation Panel Functions Overview

Explains the functions of buttons and indicators on the embroidery machine's operation panel.

Preparation Flowchart and Software Start

Provides a visual flowchart for preparation steps and details the machine power on sequence.

Machine Name Registration and Data Retrieval

Covers registering the machine name and retrieving embroidery data using the explorer.

Initiating the Embroidering Process

Explains how to check the READY lamp and initiate the embroidering process.

Selecting and Transferring Embroidery Data

Embroidery Data Explorer Functions Reference

Lists command references for file management, viewing, and tool menu operations.

Explorer Screen Layout and Navigation

Identifies major components of the Embroidery Data Explorer screen like toolbars and status bars.

Data Management: Create, Transfer, Copy, Move, Delete

Guides on how to create new directories and transfer, copy, move, and delete embroidery data files.

Reading Data from Floppy Disks and Paper Tape

Guides on reading data from floppy disks and paper tape in various formats.

Editing Embroidery Data

Embroidery Data Editing Functions Reference

Lists commands for file operations, editing, changing, and viewing embroidery data.

Display Settings and Pattern Viewing Options

Explains how to open embroidery data and adjust display settings like centering and zoom.

Needle, Stitch, and Color Configuration

Covers displaying stitch positions, needle bar settings, and thread color.

Pattern Manipulation: Resize, Delete, Insert Codes

Details how to resize embroidery patterns and delete individual stitches.

Start;End Positions, Masking, Grouping, Merging

Explains how to change embroidery start/end positions and set masking for pattern boundaries.

Saving and Printing Edited Embroidery Data

Details how to save edited data, save as a new file, and print embroidery data.

Embroidering Operations and Settings

Command Reference and Menu Functions

Lists functions available when the machine power is off and on, categorized by menu.

Settings Before and After Power On

Covers displaying toolbars, status bars, and managing windows on the screen.

Machine Settings: Needle, Speed, Hoop, Area

Covers detailed machine settings like needle bar, speed range, hoop type, and embroidery area.

Thread Trimming, Boring, and Sensor Settings

Covers boring settings, thread breakage sensor configuration, and thread trimming.

Embroidery Control: Start, Stop, Step-forward;back

Guides on starting embroidery, pausing, canceling, and controlling frame movement.

Pattern Manipulation: Centering, Saving, Other Programs

Covers centering patterns, saving data, and running other embroidery software programs.

Machine Operation Procedures

Power On and Embroidery Preparation Steps

Covers turning on the machine power and preparing for embroidery, including data selection.

Machine Stop and Emergency Procedures

Explains how to stop the machine using the stop switch and emergency stop functions.

Hoop Movement Control and Area Check

Details permission for hoop movement, jog switches, and checking the embroidery area.

Thread Breakage Measures and Inching Mode

Explains hoop feed positions and remedies for thread breakage during operation.

Creating Production Reports

Production Report Functions and Screen Layout

Lists functions for opening, saving, printing, and viewing production reports.

Displaying Detailed and Breakage Reports

Explains how to display detailed operation status and thread breakage information.

Output and Total Output Information Display

Covers displaying production output, efficiency, and total output information.

Setting Report Items and Saving Reports

Guides on setting which items to display in different production report types.

Printing and Copying Report Data

Explains how to set page properties and print the production report.

Machine Maintenance Procedures

Cleaning the Machine and Its Components

Provides instructions for cleaning the machine, rotary hook, and needle plate.

Lubrication Points and Oil Application Schedule

Details where and how to apply oil to the machine head, needle bars, and tanks.

Machine Adjustment Procedures

Needle Bar Height and Timing Adjustment

Guides on adjusting the needle bar height using pulley and stopper mechanisms.

Presser Foot and Thread Trimmer Adjustments

Explains how to adjust the presser foot height and thread trimmer components.

Thread Wiper and Belt Tension Adjustments

Details adjusting the thread wiper, finger guard, and belt tension for smooth operation.

Error Code List and Troubleshooting

Common Error Codes and Resolution Measures

Lists common error codes (E-00 to E-1F) and recommended measures for resolution.

Hoop, Needle, and Communication Related Errors

Details error codes related to hoop and needle position errors (E-21 to E-CA).

Spindle, Motor, and PCB Communication Errors

Lists errors related to spindle rotation, speed commands, and PCB communication.

Troubleshooting Guide

Mechanical Troubleshooting Checks

Provides checks for common mechanical problems like thread breakage and needle interference.

Electrical System Troubleshooting Steps

Details checks for electrical issues such as non-operation, overtravel, and sensor errors.

Optional Equipment Installation

Attaching and Using the Bobbin Winder

Guides on mounting the bobbin winder assembly and connecting its components.

Winding Lower Thread with Bobbin Winder

Explains the process of winding thread onto the bobbin using the bobbin winder.
