Why does the lower thread wind to one side on my Brother Sewing Machine?
If the lower thread winds to one side, it's likely because the height of the bobbin winder tension assembly is incorrect. Adjust the height of the bobbin winder tension assembly.
How to fix incorrect lower thread winding amount on my Brother Sewing Machine?
If the lower thread winding amount is incorrect, it is because the bobbin presser position is incorrect. Adjust the position of the bobbin presser.
How to correct work clamp lift amount on Brother Sewing Machine (KE-430HX/HS)?
If the work clamp lift amount is incorrect, it is likely due to the incorrect position of the work clamp arm lever plate. Adjust the work clamp lift amount.
How to fix work clamp not rising issue on Brother Sewing Machine (KE-430HX/HS)?
If the work clamp does not rise, it could be due to: * Sluggish work clamp operation. Grease the sliding part of the work clamp. * Too much friction between the work clamp lifter plate and work clamp arm lever plate. Grease these parts. * The work clamp contacting the thread wiper. Adjust the position of the thread wiper.
Why is the thread wiper not operating correctly on my Brother BE-438HX?
The thread wiper may not operate correctly if: * The thread wiper is obstructing the needle. Adjust the height of the thread wiper. * The operating distance of the thread wiper needs adjustment. * The thread wiper position is incorrect. Adjust the operating distance of the thread wiper.
How to fix incorrect button clamp lift amount on Brother Sewing Machine (BE-438HX/HS)?
If the button clamp lift amount is incorrect, it may be due to the incorrect position of the button clamp holder hook. Adjust the button clamp lift amount.
How to resolve button clamp not rising issue in Brother Sewing Machine (BE-438HX/HS)?
If the button clamp does not rise, it might be because the work clamp is contacting the thread wiper. Adjust the position of the thread wiper.
What causes poor seam finish on the reverse side of material with my Brother BE-438HX Sewing Machine?
A poor seam finish on the reverse side of the material can be caused by: * The shuttle race thread guide separating the threads insufficiently. Adjust its position. * The upper thread not being properly tight. Adjust the upper thread tension. * Uneven needle thread. Adjust the sub-tension. * The needle thread being too long. Adjust the sub-tension. When using the thread nipper device, turn the tension nut to adjust the upper thread trailing length to 35 – 38 mm. * The needle striking the button (BE-438HX/HS). Refer to “5-11. Checking the sewing pattern.”
Why is the upper thread not trimmed on my Brother BE-438HX?
The upper thread may not be trimmed because: * The movable knife is blunt. Replace it. * The fixed knife is blunt. Sharpen or replace it. * The movable knife does not pick up the thread. Adjust the position of the shuttle race thread guide. * The needle bar lift amount needs adjustment. * The movable knife doesn't pick up the thread because of skipped stitches. Refer to “Skipped stitches occur.” * The movable knife position is incorrect. Adjust its position. * The sub-tension is too weak. Turn the sub-tension nut to adjust the tension.
Why is my Brother Sewing Machine upper thread breaking?
The upper thread may break due to several reasons: * The upper thread tension might be too strong - adjust it. * The needle may be installed incorrectly - install it correctly. * The thread might be too thick for the needle - use the correct thread. * The thread take-up spring tension and height may be incorrect - adjust them. * The shuttle hook, needle hole plate, or needle may be damaged - file smooth or replace the part. * The thread may be melting (if it is synthetic) - use the needle cooler.
Explains DANGER, WARNING, CAUTION indications and symbols used in the manual and on the machine.
Provides safety guidelines for environmental conditions and installation procedures.
Explains the importance and procedure for connecting the ground wire.
Correct procedure for inserting the sewing needle.
Steps for winding thread onto the bobbin.
Guide for correctly inserting the bobbin case.
Instructions for threading the upper thread correctly.
Details on adjusting upper and lower thread tension for optimal sewing.
Identifies and explains each component of the operation panel.
Basic procedure for starting and performing a sewing operation.
Procedure for replacing lubricating oil when prompted.
Table of reference thread tensions for different materials.
Detailed steps for adjusting thread tension.
General| Brand | Brother |
|---|---|
| Model | BE-438HX |
| Category | Sewing Machine |
| Language | English |
