Brother DCP-8150DN Service Manual

2-25
Confidential
Jam MP Tray
The registration front sensor does not detect
paper pass within the specified time after the
paper was picked up from the MP tray.
8C00 2-47
Jam Rear
The eject sensor remains ON (paper pass
detected) for more than the specified time
even after the registration rear sensor detected
the end of paper pass.
8400 2-44
Jam Tray 1
The registration front sensor does not detect
paper pass within the specified time after the
T1 paper feed sensor detected paper pass.
8A00 2-46
Jam Tray 2
The registration front sensor does not detect
paper pass within the specified time after the
T2 paper feed sensor detected paper pass.
8B00 2-46
Log Access Error Log registration failed.
0C01
0C02
0C03
0C04
2-31
Machine Error F9 The country code was not entered correctly. F900 2-68
Manual Feed
There is no paper set in the MP tray when
feeding from the Manual is designated from
the driver.
9A00 2-52
No HUB Support
A USB device with a built-in hub is connected
to the USB terminal.
---
No Paper
When printing from the MP tray, the MP paper
empty sensor detected that there was no
paper set in the MP tray.
9300 2-49
When printing from paper tray 1, the T1 paper
feed sensor detected that there was no paper
set in paper tray 1.
9400 2-49
When printing from paper tray 2, the T2 paper
feed sensor detected that there was no paper
set in paper tray 2.
9500 2-50
When printing with the tray designation set to
AUTO, the MP paper empty sensor, T1 paper
feed sensor and T2 paper feed sensor all
detected that there was no paper set in the MP
tray, paper tray 1 and paper tray 2.
9600 2-50
No Toner
The toner sensor detected that the toner
cartridge was not set.
4400 2-35
No Tray
The T1 paper feed sensor detected that paper
tray 1 was not set.
8500 2-45
Out of Memory
There is insufficient memory to expand PC-
print data.
C700 2-61
The memory size allotted for Secure Print was
exceeded when saving Secure Print data.
C800 2-61
The program cannot be updated due to
insufficient memory.
---
Replace Parts Drum
The number of rotations of the drum unit has
reached the life limit. (Printing does not stop.)
5000 2-35
Replace Parts Fuser
Unit
Printable pages set for the fuser unit have
reached the limit. (Printing does not stop.)
5400 2-36
Replace Parts Laser
Unit
Printable pages set for the laser unit have
reached the limit. (Printing does not stop.)
5500 2-36
Error Message Description
Error
codes
Refer
to:

Brother DCP-8150DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	10.5 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Duplex media weight (imperial)	16 - 28 lbs
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 43 lbs
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.4 W
Power consumption (PowerSave)	8.1 W
Power consumption (average operating)	702 W
Package depth	533.4 mm
Package width	594.36 mm
Package height	604.52 mm
Package weight	19800 g
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	414.02 mm
Width	490.22 mm
Height	447.04 mm
