Brother HL-2250DN Technical Reference Guide

CHAPTER 3 PCL5C - 7
(i.e.)
ESC*b#V r, r, r, r, r... Plane 1 1st raster
ESC*b#V g, g, g, g
, g... Plane 2
ESC*b#W b, b, b, b
, b... Plane 3
ESC*b#V r, r, r, r, r... Plane 1 2nd raster
ESC*b#V g, g, g, g, g... Plane 2
** The Italic characters shown above are the index No. at the 4th pixel in the 1st raster.
[Example]
If you want to send RGB=(1,1,1)(0,1,1)(1,0,1)(0,0,1)(1,1,0)(0,1,0)(1,0,0)(0,0,0);
** The values in the brackets show the RGB value of the pixel.
Enter 'ESC*v6W 00h 02h 01h 01h 01h 01h', then select Send Direct Value by Plane.
Select 1 bit/index.
ESC*r1A Start Raster Transfer
ESC*b1V 10101010B Send Plane 1 data (Red data)
ESC*b1V 11001100B Send Plane 2 data (Green data)
ESC*b1W 11110000B Send Plane 3 data (Blue data)
ESC*rC End Raster Transfer
(xxh: hexadecimal, xxxxxxxxB: binary)
Send Direct Value by Pixel (= 3)
 This sends each value of RGB pixel by pixel.
 Bits/index must be 8.
(i.e.)
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 1st raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 2nd raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 3rd raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 4th raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 5th raster
** The Italic characters shown above are the index No. at the 4th pixel in the 1st raster.
[Example]
If you want to send the RGB value below;
RGB value.
(0,0,0)(128,128,128)(128,64,0)(255,128,64)
1st raster
(128,128,128)(128,64,0)(255,128,64) (0,0,0) 2nd raster
(128,64,0)(255,128,64) (0,0,0) (128,128,128) 3rd raster
** The values in the brackets show the RGB value of the pixel.
Enter 'ESC*v6W 00h 03h 08h 08h 08h 08h', then select Send Direct Value by Pixel.
Select 8 bits/index.
ESC*r1A Start Raster Transfer
ESC*b12V 00h 00h 00h 80h 80h 80h 80h 40h 00h ffh 80h 40h Send Plane 1 data (Red data)
ESC*b12V 80h 80h 80h 80h 40h 00h ffh 80h 40h 00h 00h 00h Send Plane 2 data (Green data)
ESC*b12W 80h 40h 00h ffh 80h 40h 00h 00h 00h 80h 80h 80h Send Plane 3 data (Blue data)
ESC*rC End Raster Transfer
(xxh: hexadecimal, xxxxxxxxB: binary)

Brother HL-2250DN Specifications

General

Color	No
N-up printing	2, 4, 6, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Maximum internal memory	- MB
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Maximum duty cycle	- pages per month
Page description languages	PCL 6
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	0.9 W
Package weight	8300 g
Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
