Brother HL-5340D User Manual

Appendix
142
A
Dimensions / weights 0
Other 0
1
We do not recommend Toner Save for printing Photo or Grey Scale images.
Model HL-5340D HL-5350DN HL-5370DW
Dimensions (W × D × H) 371 × 384 × 246 mm (14.6 × 15.1 × 9.7 in.)
Weights Approx. 9.5 kg (20.9 lb)
Model HL-5340D HL-5350DN HL-5370DW
Power consumption Printing Average 675 W at
25 °C (77 °F)
Average 675 W at
25 °C (77 °F)
Average 675 W at
25 °C (77 °F)
Standby Average 75 W at
25 °C (77 °F)
Average 75 W at
25 °C (77 °F)
Average 75 W at
25 °C (77 °F)
Sleep Average 6 W Average 6 W Average 6 W
Noise level Sound Pressure Printing 54 dB (A)
Standby 35 dB (A)
Sound power Printing LWAd = 7.0 Bell (A)
Standby LWAd = 4.8 Bell (A)
Ecology Power save Yes
Toner save
1
Yes
Downloaded from ManualsPrinter.com Manuals

Brother HL-5340D Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Maximum internal memory	528 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	75 W
Power consumption (printing)	675 W
Power consumption (PowerSave)	6 W
Custom media width	76.2 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Package weight	11.700 g
Maximum duty cycle	- pages per month
Number of print cartridges	1
Standard interfaces	Parallel, USB 2.0
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
