Brother HL-5350DN Technical Reference Guide

CHAPTER 3 PCL5C - 7
(i.e.)
ESC*b#V r, r, r, r, r... Plane 1 1st raster
ESC*b#V g, g, g, g
, g... Plane 2
ESC*b#W b, b, b, b
, b... Plane 3
ESC*b#V r, r, r, r, r... Plane 1 2nd raster
ESC*b#V g, g, g, g, g... Plane 2
** The Italic characters shown above are the index No. at the 4th pixel in the 1st raster.
[Example]
If you want to send RGB=(1,1,1)(0,1,1)(1,0,1)(0,0,1)(1,1,0)(0,1,0)(1,0,0)(0,0,0);
** The values in the brackets show the RGB value of the pixel.
Enter 'ESC*v6W 00h 02h 01h 01h 01h 01h', then select Send Direct Value by Plane.
Select 1 bit/index.
ESC*r1A Start Raster Transfer
ESC*b1V 10101010B Send Plane 1 data (Red data)
ESC*b1V 11001100B Send Plane 2 data (Green data)
ESC*b1W 11110000B Send Plane 3 data (Blue data)
ESC*rC End Raster Transfer
(xxh: hexadecimal, xxxxxxxxB: binary)
Send Direct Value by Pixel (= 3)
 This sends each value of RGB pixel by pixel.
 Bits/index must be 8.
(i.e.)
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 1st raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 2nd raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 3rd raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 4th raster
ESC*b#W r, g, b, r, g, b, r, g, b, r, g, b,... 5th raster
** The Italic characters shown above are the index No. at the 4th pixel in the 1st raster.
[Example]
If you want to send the RGB value below;
RGB value.
(0,0,0)(128,128,128)(128,64,0)(255,128,64)
1st raster
(128,128,128)(128,64,0)(255,128,64) (0,0,0) 2nd raster
(128,64,0)(255,128,64) (0,0,0) (128,128,128) 3rd raster
** The values in the brackets show the RGB value of the pixel.
Enter 'ESC*v6W 00h 03h 08h 08h 08h 08h', then select Send Direct Value by Pixel.
Select 8 bits/index.
ESC*r1A Start Raster Transfer
ESC*b12V 00h 00h 00h 80h 80h 80h 80h 40h 00h ffh 80h 40h Send Plane 1 data (Red data)
ESC*b12V 80h 80h 80h 80h 40h 00h ffh 80h 40h 00h 00h 00h Send Plane 2 data (Green data)
ESC*b12W 80h 40h 00h ffh 80h 40h 00h 00h 00h 80h 80h 80h Send Plane 3 data (Blue data)
ESC*rC End Raster Transfer
(xxh: hexadecimal, xxxxxxxxB: binary)

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
