Brother HL-5350DN Technical Reference Guide

CHAPTER 2 PCL - 54
Symbol map (Array of UI )
The symbol map, which has a list of symbol index numbers, is used to define the symbols for the symbol set.
This map defines the combinations of symbol index numbers and character codes.
5.2.4. Symbol set control command
Esc*c#S (27)(42)(99)#(83) <1Bh><2Ah><63h>#<53h>
 Values for # can be 0, 1, 2, 4, or 5.
 0 specifies to delete all temporary and permanent user-defined symbol sets.
 1 specifies to delete all temporary user-defined symbol sets.
 2 specifies to delete current user-defined symbol set.
 4 specifies to make current user-defined symbol set temporary.
 5 specifies to make current user-defined symbol set permanent.
5.2.5. Selecting the symbol set
Esc(symbol set ID (27)(40) <1Bh><28h>
 This command selects the symbol set (character set) for the primary font.
 Symbol set IDs consist of a number followed by a letter.
 Default symbol set ID is Roman-8. If an invalid default symbol set ID is selected, the symbol set becomes
Roman-8.
 The selectable symbol set varies depending on the printer model.
Symbol set Set primary font Symbol set Set primary font
ISO 60 : Norwegian 1 Esc(0D ISO 57 : Chinese Esc(2K
ISO 61 : Norwegian 2 Esc(1D ISO8859-1 (ECMA-94) Latin
1
Esc(0N
ISO 4 : United Kingdom Esc(1E Wingdings Esc(579L
Windows 3.1 Latin 2 Esc(9E PS Math Esc(5M
ISO 25 : French Esc(0F Ventura Math Esc(6M
ISO 69 : French Esc(1F Math-8 Esc(8M
HP German Esc(0G Symbol Esc(19M
ISO 21 : German Esc(1G ISO 8859-2 Latin 2 Esc(2N
ISO 15 : Italian Esc(0I ISO 8859-9 Latin 5 Esc(5N
Microsoft Publishing Esc(6J ISO 11: Swedish; names Esc(0S
Desk Top Esc(7J PS Text Esc(10J
HP Spanish Esc(1S Ventura International Esc(13J
ISO 17 : Spanish Esc(2S Ventura US Esc(14J
ISO 10 : Swedish Esc(3S ISO 16 : Portuguese Esc(4S
ISO 14 : JIS ASCII Esc(0K ISO 84 : Portuguese Esc(5S
ISO 85 : Spanish Esc(6S Windows 3.1 Latin 5 Esc(5T
PC Turkish Esc(9T ISO 6 : ASCII Esc(0U
Legal Esc(1U ISO 2 : IRV Esc(2U
Roman 8 Esc(8U Windows 3.0 Latin 1 Esc(9U
PC-8 Esc(10U PC-8 D/N Esc(11U
PC-850 Esc(12U Pi Font Esc(15U
PC-852 Esc(17U Windows 3.1 Latin 1 Esc (19U
MC Text Esc(12J ISO 8859-10 Latin 6 Esc (6N
OCR-A Esc(0O OCR-B Esc(1O

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
