CHAPTER 2 PCL - 68
Symbol set name Symbol set ID Symbol set name Symbol set ID
Default Se
t
0
@
Math-7 0A
Line Draw-7 0B HP Lar
g
e Characters
(
264x Terminals
)
0C
ISO 60: Danish/Norwe
g
ian 0D ISO 61: Norwe
g
ian version 2 1D
Roman Extensions 0E ISO 4: United Kin
g
do
m
1E
ISO 25: French 0F ISO 69: French 1F
HP German 0G ISO 21: German 1G
Gree
k
-8 8G Hebrew-7 0H
Hebrew-8 8H ISO 15: Italian 0I
Microsoft Publishin
g
6J DeskTo
p
7J
Documen
t
8J PS Tex
t
10J
Ventura International 13J Ventura US 14J
ISO 14: JIS ASCII 0K ISO 13: Katakana 1K
ISO 57: Chinese 2K Kana-8 8K
Korean-8 9K Line Draw-7
(
Same as 0B
)
0L
HP Block Characters 1L Tax Line Draw 2L
Line Draw-8 8L Math-7
(
Same as 0A
)
0M
Tech-7 1M PS Math 5M
Ventura Math 6M Math-8 8M
ECMA-94 Latin 1
(
ISO 8859/1
)
0N ECMA-94 Latin 2
(
ISO 8859/2
)
2N
ECMA-128 Latin 5
(
ISO 8859/9
)
5N ECMA-113/88 Latin/C
y
rillic 10N
OCR A 0O OCR B 1O
OCR M 2O APL
(
T
yp
ewriter Paired
)
0P
APL
(
Bit Paired
)
1P S
p
ecials x
Q
C
y
rillic ASCII
(
ECMA-113/86
,
0R C
y
rillic 1R
PC C
y
rillic 3R ISO 11: Swedish for Names 0S
HP S
p
anish 1S ISO 17: S
p
anish 2S
ISO 10: Swedish 3S ISO 16: Portu
g
uese 4S
ISO 84: Portu
g
uese 5S ISO 85: S
p
anish 6S
HP Euro
p
ean S
p
anish 7S HP Latin S
p
anish 8S
HP-GL Download 16S HP-GL Draftin
g
17S
HP-GL S
p
ecial S
y
mbols 18S Turkish-8 8T
Thai-8 0T ISO 6: ASCII 0U
Le
g
al 1U ISO 2: International Reference Version 2U
HP-GL Lan
g
ua
g
e Se
t
5U OEM-1 7U
Roman-8 8U Windows 9U
PC-8 10U PC-8 D/N
(
Danish/Norwe
g
ian
)
11U
PC-850 12U PC-852 17U
Pi Fon
t
15U
Arabic (McKay
'
s version)
0V
Arabic-8 8V 3 of 9 Barcode 0Y
Industrial 2 of 5 Barcode 1Y Matrix 2 of 5 Barcode 2Y
Interleaved 2 of 5 Barcode 4Y CODABAR Barcode 5Y
MSI/Plesse
y
Barcode 6Y Code 11 Barcode 7Y
UPC/EAN Barcode 8Y USPS Zi
p
15Y
 Pitch (UI) - This value defines the default spacing for each point size in 1/4 dots. Combined with Pitch
Extended to specify the pitch of the font in 1/1024 dots. This is available for fixed pitch font characters
including the space character, and the space character of proportional spacing fonts.
For example, in case of a 17 cpi font (at 600 dpi),
= 141.17646
1 inch 600 dpi
4
17 chara.
1 inch 1
the value of Pitch (UI) should be 141.
The remainder of 0.17646 is calculated as pitch extended:
0.17646 256
4 1
= 45.17376
the value for pitch extended is 45.
