Brother HL-5350DN User Manual

viii
4 Control Panel
75
LEDs (Light Emitting Diodes)...................................................................................................................75
Service call indications ............................................................................................................................81
Control panel buttons...............................................................................................................................83
Print a test page ................................................................................................................................84
Print the Printer Settings page...........................................................................................................85
Print Fonts .........................................................................................................................................86
Default settings..................................................................................................................................87
5 Options
88
Lower tray (LT-5300) ...............................................................................................................................88
SO-DIMM (memory module)....................................................................................................................89
SO-DIMM types .................................................................................................................................89
Installing extra memory .....................................................................................................................90
6 Routine Maintenance
92
Replacing the consumable items.............................................................................................................92
Consumables.....................................................................................................................................92
Toner cartridge ..................................................................................................................................93
Drum unit .........................................................................................................................................100
Cleaning ................................................................................................................................................105
Cleaning the outside of the printer...................................................................................................105
Cleaning the inside of the printer.....................................................................................................107
Cleaning the paper pick-up roller.....................................................................................................110
Cleaning the corona wires .....................................................................................................................112
Cleaning the corona wire.................................................................................................................112
7 Troubleshooting
114
Identifying your problem ........................................................................................................................114
Error messages in the Status Monitor ...................................................................................................115
Error message printout ..........................................................................................................................117
Paper handling ......................................................................................................................................118
Paper jams and how to clear them ........................................................................................................119
Jam MP tray / Tray1 / Tray2 / Tray3 / Inside ...................................................................................119
Jam Rear / Duplex...........................................................................................................................124
Improving the print quality......................................................................................................................128
Solving print problems ...........................................................................................................................135
Network problems (For HL-5350DN and HL-5370DW) .........................................................................136
Other problems......................................................................................................................................136
For Macintosh® with USB ...............................................................................................................136
BR-Script 3 ......................................................................................................................................137
Downloaded from ManualsPrinter.com Manuals

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
