Introduction
4
1
Types of network connections 1
Network connection example 1
Peer-to-Peer printing using TCP/IP 1
In a Peer-to-Peer environment, each computer directly sends and receives data to each device. There is no
central server controlling file access or printer sharing.
1) Router
2) Network printer (your machine)
In a smaller network of 2 or 3 computers, we recommend the Peer-to-Peer printing method as it is easier
to configure than the Network Shared printing method. See Network Shared printing on page 5.
Each computer must use the TCP/IP Protocol.
The Brother machine needs to have an appropriate IP address configuration.
If you are using a router, the Gateway address must be configured on the computers and the Brother
machine.
2
TCP/IPTCP/IP
Windows
R
Windows
R
1
Windows
R
To Next Page
